MCR10 Hydraulic Drive Motor 2560-4400 N.M Torque For Skid Steer Loader

Features:

Rexroth MCR10/MCRE10 Series Hydraulic Motors

1. Radial piston design.
2. Higher output torques, lower output speed, smoother output speed at low speeds.
3. Optimized and modular design capable of delivering high performance.
4. Highly efficient at any speed or operating pressure.
5. Withstand the most extreme operating conditions and require very little maintenance.

MCR10 Displacement Diagram

Code	HMCR10			HMCRE10
Displacement Group	0	1	2	0	1	2
Displacement(ml/r)	780	860	940	1120	1250	1340
Theoretical torque at 10Mpa(N.m)	1240	1367	1494	1780	1987	2130
Rated speed(r/min)	125	100	100	100	80	80
Rated pressure(Mpa)	25	25	25	25	25	25
Rated torque(N.M)	2560	2820	3090	3680	4110	4400
Max.pressure(Mpa)	31.5	31.5	31.5	31.5	31.5	31.5
Max.torque(N.m)	3160	3480	3810	4540	5060	5430
Speed range(r/min)	0-215	0-195	0-180	0-150	0-135	0-125
Max.power(kW)	44	44	44	50	50	50

MCR10 Application:

Mining Machinery: Coal Winning Machine,Road Header,Heavy Duty Handling Car, Coal Mine Drill

Engineering Machinery:Skid Steer Loader,Break Machine




Ningbo Helm Tower Noda Hydraulic Co.Ltd is belong to Ningbo wenkui group, which is a

professional designer,manufacturer and exporter for Poclain MS / Rexroth MCR motors and parts

Rexroth pumps and parts: A2FO, A2F, A2VK, A4V, A4VF, A6V, A8VO, A10VG, A10V, A10VSO, A11VO...

HDC,HTC,HFSeries Drum cutter, hydraulic winch.

Our company located in Ningbo, Holding $5 million registered capital, covering area is over

l0,000 square meters, it is very near and convenient to the seaport and airport,our

products are widely used in Marine, Coal mine machinery, Agriculture,Forest machinery,

Forklit,Skid loader, Excavator, Road machinery, Construction machinery.

Our production equipment includeing Korea Horizontal Machining Center(KH50G), Three-Dimensional Measuring Instrument, Incurve Machining Center(Verical Numerical Control Curve Grinding Machine MK8580), Vertical Machining Center(VMC4020A), Rotor Slot grinding Machinc(Numerial Control High Power Grinding Form Machine MKL7132*8.5), and our under construction automatic production line.

The automatic production line of rotor has been put into production in end of 2019, annual production of 34,000 pcs

We not only have a strict manual inspection standard during the production line, but also have a motor test center and pump test center. And we passed ISO9001:2008. CCS ,TUV and SGS certificate.

We had a strong R&D, technology support team, most of them working in the hydraulic

industry over 10 years, we use high grade alloy steel material, also adopted advance heat

treatment QPQ, with advance process equipment which import from USA, CNC machine, all of

this ensure our MS and MCR hydraulic motor and spare parts can be completely replace

original brand on the dimension and performance character,Our production delivery time is

shorter; we have enough stock for the spare parts, so that we can delivery to customer in

one week.

Our products was widely export to USA, European, South American, Australian,African,Midde

East, South east Asia, and other countries and region..
With competitive price, excellent performance and prompt. delivery, we sincerely welcome

you establish co-operative.
