    Hydraulic Piston Pump A10V Radial Loading High Pressure Axial

    Ask Lasest Price
    Brand Name : Helm Tower
    Model Number : Rexroth A10V
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 2000 pieces per month
    Delivery Time : 5 days
    • Product Details
    • Company Profile

    Hydraulic Piston Pump A10V Radial Loading High Pressure Axial

    Hydraulic Piston Pump A10V , Radial Loading High Pressure Axial Piston Pump


    Features:


    A10V variable displacement hydraulic piston pump

    Nominal pressure 280Bar, Peak pressure 350Bar;

    Swash plate design axial variable piston pump used in open circuit.
    Continuous work pressures can reach 280bar; the highest instantaneous work pressure can reach 350bar.
    The flow is directly proportional to the drive rotate speed and the displacement, and can make stepless variable come true by adjusting the obliquity of the swash plate.
    There are various of control type such as DR, DFR, DFLR etc. and the control response is very fast.
    Low noises level, High efficiency, High reliability and long time service life.
    Small volume, High power density.
    Excellent oil absorbency.
    Axial and radial loading of drive shaft possible
    SAE and ISO mounting flange

    Thru shaft configuration use in circuit system


    DRDRF/DRSLADFEED (RE 92707)
    Pressure controllerPressure and flow controllerPressure, flow and power controllerPressure and flow controller, electronicElectrohydraulic closed-loop pressure control

    Appliation:


    Our pumps are mainly used for construction machinery, geological drilling equipment, special vehicles,mining machinery, lifting and transporting equipment, cranes, ship machinery, agricultural and forestry machinery, and so on.



    Specification data:


    TypeA10VSO16A10VSO18A10VSO28A10VSO45A10VSO71A10VSO100A10VSO140
    Sizes1818284571100140
    DisplacementVg maxcm31818284571100140
    Max speednmaxrpm3300330030002600220020001800
    Max. flowIn nmaxqvL/min59.459.484117156200252
    in 1500 r/min27274268107150210
    (¦¤p=280bar)in nmaxPmaxKw27.727.739557393118
    Max. powerin 1500 r/min12.612.62032507098
    (¦¤p=280bar)in Vg maxTmaxNm80.180.1125200316445623
    Max. torque
    WeightmKg12121521334560
